5MP OS02C10 Large View Angle Fixed Focus MIPI Endoscope Camera Module
Factory Direct Sales Large View Angle Fixed Focus OS02C10 5MP MIPI Endoscope Camera Module
HAMPO-IRSW-OS02C10 V1.2 is a 5MP OmniVision OS02C10 IR Switch MIPI Interface M14 Fixed Focus Camera Module.It uses 0.5mm and 1mm Pitch Connectors For FPC/FFC.Output formats: linear output, dual exposure HDR (long and short),
3-exposure HDR (long, short, and very short), conversion gain programmable in each channel.Wide applications :Security Camera ,Action Camera ,High Resolution Consumer Camera.
Specification
|
Camera Module No.
|
HAMPO-IRSW-OS02C10 V1.2
|
|
Resolution
|
5MP
|
|
Image Sensor
|
OS02C10
|
|
Sensor Size
|
1/2.8"
|
|
Pixel Size
|
2.9 um x 2.9 um
|
|
EFL
|
1.75 mm
|
|
F/No.
|
2.00
|
|
Pixel
|
1920 x 1080
|
|
View Angle
|
200.0°(DFOV) 200.0°(HFOV) 100.0°(VFOV)
|
|
Lens Dimensions
|
16.20 x 16.10 x 12.82 mm
|
|
Module Size
|
56.47 x 30.00 mm
|
|
Focusing
|
Fixed Focus
|
|
Interface
|
MIPI
|
|
Mating Connector
|
FH12-24S-0.5SH
|
|
Operating Temperature
|
-30°C to +85°C
|
Key Features
QE enhancement in NIR range
support for image size:
- 1920 x 1080
- VGA
- QVGA, and any cropped size
- 1920 x 1080
- VGA
- QVGA, and any cropped size
high dynamic range
high sensitivity
programmable conversion gain
image sensor processor functions:
- defective pixel cancelation
- automatic black level correction, etc.
- defective pixel cancelation
- automatic black level correction, etc.
Applications
