OV9281 Globa Shutter HD 1MP FF MIPI Camera Module
OV9281 Globa Shutter HD 1MP FF MIPI Camera Module
HAMPO-E3MPF-OV9281 V1.0 NIR is a 1MP OmniVision OV9281 Global Shutter MIPI and DVP Interface No IR Fixed Focus Camera Module.It uses 0.4 mm Pitch, 0.9 mm Height, Board-to-Board / Board-to-FPC Connectors.
APPLICATIONS :Cellular phones, PDA's, mobile computers, digital cameras, digital video cameras, and other devices demanding high reliability connections in extremely limited spaces.
Specification
|
Camera Module No.
|
HAMPO-E3MPF-OV9281 V1.0 NIR
|
|
Resolution
|
1MP
|
|
Image Sensor
|
OV9281 Global Shutter
|
|
Sensor Size
|
1/4"
|
|
Pixel Size
|
3.0 um x 3.0 um
|
|
EFL
|
3.20 mm
|
|
F/No.
|
2.80
|
|
Pixel
|
1296 x 816
|
|
View Angle
|
70.0°(DFOV) 58.6°(HFOV) 45.3°(VFOV)
|
|
Lens Dimensions
|
8.50 x 8.50 x 4.75 mm
|
|
Module Size
|
24.00 x 8.50 mm
|
|
Focusing
|
Fixed Focus
|
|
Interface
|
MIPI and DVP Parallel
|
|
Auto Focus VCM Driver IC
|
None
|
|
Lens Type
|
No IR Filter Lens
|
|
Operating Temperature
|
-30°C to +85°C
|
Key Features
*3 µm x 3 µm pixel with OmniPixel®3-GS technology
*automatic black level calibration (ABLC)
*programmable controls for:
- frame rate
- mirror and flip
- cropping
- windowing
- frame rate
- mirror and flip
- cropping
- windowing
*support output formats: 8/10-bit RAW
*fast mode switching
*supports 2x2 monochrome binning
*two-lane MIPI serial output interface
*DVP parallel output interface
Applications
Consumer HMD
Drones
Machine Vision
PCNB
