2MP AR0234 Global Shutter Color Camera Module
Global Shutter Color Image 1/2.6" Onsemi AR0234 Sensor Full HD 60FPS High Frame Rate USB2.0 Camera Module
Description:
Hampo 003-1858 is a 1080P full HD color image global shutter camera module for accurate and fast capture of moving scenes at 60fps in 2MP resolution. This Global shutter USB camera features a 1/2.6" AR0234 CMOS Image Sensor with a pixel size of 3.0µm x 3.0µm and a dedicated high-performance Digital Signal Processor (DSP), that performs all the Auto functions (Auto White Balance, Auto Exposure control). This global shutter camera captures images at a high frame rate, which helps to minimize frame-to-frame distortion and reduce motion blur while capturing fast-moving objects to produce smoother images with greater scene details.
Both global shutter and high frame rate make it suitable for applications such as Automatic Number Plate Recognition (ANPR), Autonomous Mobile Robots (AMR), Gesture Recognition, Robotic Vision, Drones, Barcode Scanning, Factory Automation, Conveyor Monitoring Cameras, Position tracking, and Traffic Monitoring Systems.
Feature:
Based on 2MP color global shutter 1/2.6" Optical Form-factor AR0234 sensor, assembled with a no distortion M12 lens without IR pass filter, sensitive to IR.
Global Shutter: Shoot high-speed moving objects in crisp sharp images. Avoid the rolling artifacts to get a much more accurate complete picture than the rolling shutter cameras. Reserved external trigger ports, support trigger via external signal.
Resolution: 2.3MP @60fps;
Plug&Play: UVC-compliant, just connect the camera to a PC, laptop, Android device, or Raspberry Pi with the USB cable without extra drivers to be installed.
Applications: The sensor's excellent low-light sensitivity and the low distortion lens allow it to perform better in any application that needs gesture and eye tracking, iris and physiognomy recognition, and depth and motion detection.
SPECS
| Camera | |
| Pixel | 2.3 Mega Pixel |
| Sensor | 1/2.6’’ On Semiconductor AR0234 Sensor |
| Frame Rate | 60fps |
| Pixel Size | 3.0μm*3.0μm |
| Output Format | YUY2/MJPG |
| Shutter Type | Global Shutter |
| Chroma | Color image |
| Focus | Fixed focus |
| FOV | D=125° H=91° |
| S/N ratio | 38dB |
| Dynamic range | 71.4dB |
| Responsivity | 56 Ke-/luxsec |
| Interface type | USB2.0 |
| Adjustable parameter | Brightness/Contrast/Color saturation/Hue/Definition |
| Gamma/White balance/Exposure | |
| Lens | Focal length: 3.6mm |
| FOV: 125° non distortion | |
| Thread Size | M12*P0.5 |
| Working Current | MAX 200mA |
| Voltage | DC 5V |
| Auto Exposure Control | Support |
| Auto White Balance | Support |
| Auto Gain Control | Support |
| Interface | USB2.0 |
| Operating Temp | -4°F~158°F (-20°C~+70°C) |
| PCB Size | 32*32MM(Hole pitch compatible with 28x28mm) |
| Cable Length | Default 1.5M |
| TTL | 22MM |
| Support OS | Windows XP(SP2,SP3),Vista ,7,8,10,Linux or OS with UVC driver |
Application
Security Monitor, Industrial Machine, Self-service Cell Phone, ATM, AIO, Access Control, Airport Security Checking, Drone, Smart Medical Biometrics, Human-computer Interaction,Industrial Automation
